12V DC LED Strip Rope Lights Non-Waterproof SMD5050 Flexible LED Ribbon For Indoor Decoration

DC12V 72W 5Meter (16.4Ft) SMD5050 300LEDs/Roll Color Rendering Index CRI80 Flexible LED Strips 60LEDs/M 14.4W Per Meter Ribbon Lamp 10mm Wide White PCB

Drawing per 5000mm for non-waterproof strip (1inch=25.4mm)

Waterproof Strip Dimension

*Non-waterproof : Bare Strip, with self-adhesive backing, for indoor or dry location use.
*Waterproof IP65 : Strip Surface is covered on top with Gel, and with self-adhesive backing. IP65 grade can protect sprayed water from all direction.
*Waterproof IP67: The bare strip is put in a hollow silicone tube and sealed at two ends. IP67 grade can shortly immersed in water.
*Waterproof IP68: The bare strip is put in a U Shape silicone tube, then covered on top with silicon gel, and sealed at two ends, which make it's solid.IP68 grade can be used under water.

How to power/control the strip

#1 When choosing the transformer, the wattage to choose depends on how many pieces light strips it power. And when choosing the transformer, we suggest to use a bigger wattage transformer than the strip rated power to  avoid full load working of the transformer. And a big power transformer do no harm to the strip but good for safty.

#2 The length run in a string of strips in serial is suggested to be 5meter max, if too long, there is voltage drop will cause dim at the back end of the string.

Below please find the connection diagram for Single Color Light Strip for reference.
